Ali Hajiabadi

Transparent hardware-level memory compression has become increasingly attractive for commercial deployment, particularly in hyperscalers and cloud infrastructures. While it is well known that compression can introduce data-dependent leaks, as the compressibility of data inherently depends on its content, a common intuition is that such leaks can be mitigated using constant-time compression algorithms. Unfortunately, as we show in this paper, despite constant-time compression algorithms, all existing designs suffer from information leakage vulnerabilities due to inherently-insecure architectural design decisions. We develop several novel leakage primitives that exploit the fundamental design aspects shared across existing proposals. Relying on these leakage primitives, we show secret-dependent behaviors in widelyused cryptographic libraries and construct an end-to-end attack that leaks passwords from a popular web server. To secure memory compression against these serious vulnerabilities, we introduce a new compression non-interference property and prove that a compression system that adheres to this property does not introduce any leakage primitives. We then demonstrate that practical and secure memory compression is achievable by designing a new secure memory compression system called ZipLock. Our evaluation shows that compared to the insecure state-of-the-art baseline, ZipLock incurs only 3.5% performance overhead while providing a similar compression rate of 1.65x.

Rowhammer remains a major security concern for modern DRAM, yet no deterministic solution exists in commercial devices. The latest JEDEC specification introduces Per Row Activation Counting (PRAC) to provide a principled framework for secure in-DRAM mitigation. Since the introduction of PRAC, a number of mitigations have been proposed based on PRAC. However, these proposals only provide ad hoc security analyses without necessarily considering the worst-case scenarios. In this work, we define PRAC contracts that provide formal bounds for a generic set of mechanisms in a PRAC mitigation. Our key insight is that these generic mechanisms introduce gaps in tracking accesses to DRAM, making it possible for an attacker to craft a variety of strategies that silently survive the mitigation actions performed by PRAC. Using these silent survival strategies, we then construct EchoTrail, a provably optimal attack structure against PRAC contracts. Leveraging EchoTrail, we then develop VeriPRAC, an automatic contract verification tool that checks a given PRAC-based mitigation against its intended PRAC contract. VeriPRAC finds that all state-of-the-art mitigations violate their intended contract, and in one case, an aggressor can reach up to 7.5k activations despite the intended bound of the contract being only 99.

Despite efforts by DRAM vendors to mitigate Rowhammer, it is still a potent attack vector. CPU vendors are reluctant to deploy deterministic mitigations against Rowhammer due to the high cost that needs to be paid for the most vulnerable DRAM device, even though an average DRAM device is considerably less vulnerable. The main reason for this high cost is the need to track an increasing number of aggressor rows with the worsening Rowhammer threshold. Our proposed in-CPU mitigation, called CHaRM, breaks this dependency by efficiently mapping a large number of rows to a fixed number of hashed counters. Since multiple rows are now mapped to a limited number of counters, collisions can occur. To avoid excessive mitigative refreshes upon collisions, CHaRM deploys a checkpointing mechanism that saves the state of rows evicted from the table. When a row is activated again, CHaRM restores its checkpointed value and resumes tracking. Our evaluation shows that CHaRM incurs negligible slowdown, below 1% across all Rowhammer thresholds, while improving area, power, and energy by 3.8×, 4.4×, and 8.2×, respectively, for Rowhammer threshold of 1K compared to the state of the art.

Constant-time programming is a widely deployed approach to harden cryptographic programs against side channel attacks. However, modern processors often violate the underlying assumptions of standard constant-time policies by transiently executing unintended paths of the program. Despite many solutions proposed, addressing control flow misspeculations in an efficient way without losing performance is an open problem. In this work, we propose Cassandra, a novel hardware/software mechanism to enforce sequential execution for constant-time cryptographic code in a highly efficient manner. Cassandra explores the radical design point of disabling the branch predictor and recording-and-replaying sequential control flow of the program. Two key insights that enable our design are that (1) the sequential control flow of a constant-time program is mostly static over different runs, and (2) cryptographic programs are loop-intensive and their control flow patterns repeat in a highly compressible way. These insights allow us to perform an upfront branch analysis that significantly compresses control flow traces. We add a small component to a typical processor design, the Branch Trace Unit, to store compressed traces and determine fetch redirections according to the sequential model of the program. Despite providing a strong security guarantee, Cassandra counterintuitively provides an average 1.85% speedup compared to an unsafe baseline processor, mainly due to enforcing near-perfect fetch redirections.

Power side-channel attacks exploit the correlation of power consumption with the instructions and data being processed to extract secrets from a device (e.g., cryptographic keys). Prior work primarily focused on protecting small embedded micro-controllers and in-order processors rather than high-performance, out-of-order desktop and server CPUs. In this paper, we present PARADISE, a general-purpose out-of-order processor with always-on protection, that implements a novel dynamic instruction scheduler to provide obfuscated execution and mitigate power analysis attacks. To achieve this, we exploit the time between operand availability of critical instructions (slack) and create high-performance random schedules. Further, we highlight the dangers of using incorrect adversarial assumptions, which can often lead to a false sense of security. Therefore, we perform an extended security analysis on AES-128 using different levels of adversaries, from basic to advanced, including a CNN-based attack. Our advanced security evaluation assumes a strong adversary with full knowledge of the countermeasure and demonstrates a significant security improvement of 556× when combined with Boolean Masking over a baseline only protected by masking, and 62, 500× over an unprotected baseline. The resulting overhead in performance, power and area of PARADISE is 3.2%, 1.2% and 0.8% respectively.

In this work, we propose a new attack called Conjuring that exploits one of the main features of CPUs’ frontend: speculative fetch of instructions. We show that the Pattern History Table (PHT) in modern CPUs are a great channel to learn and leak control flow of victim applications. Unlike prior work, Conjuring does not require that one primes the PHT or interferes with the victim execution enabling a realistic and unprivileged attacker to leak control flow information. By improving the branch predictors, our attack becomes even more serious and practical. We demonstrate the feasibility of our attack on different existing Intel, AMD, and Apple CPUs.

Spectre-type attacks have exposed a major class of vulnerabilities arising from speculative execution of instructions, the main performance enabler of modern CPUs. These attacks speculatively leak secrets that have been either speculatively loaded (seen in sandboxed programs) or non-speculatively loaded (seen in constant-time programs). Various hardware-only defenses have been proposed to mitigate both speculative and non-speculative secrets via all potential transmission channels. However, limited program knowledge is exposed to the hardware and these solutions conservatively restrict the execution of all instructions that can potentially leak. In this work, we show that not all instructions depend on older unresolved branches and they can safely execute without leaking speculative information. We present Levioso, a novel hardware/software co-design, that provides comprehensive secure speculation guarantees while reducing performance overhead compared to existing defenses. Levioso informs the hardware about true branch dependencies and applies restrictions only when necessary. Our evaluations demonstrate that Levioso is able to significantly reduce the performance overhead compared to two prior defenses from 51% and 43% to just 23%.

Transient execution attacks constitute a major class of attacks affecting all modern out-of-order CPUs. These attacks exploit transient execution windows (i.e., the instructions that execute but never commit) to leak confidential information from victims. Existing attacks either rely on branch mispredictions, incorrect memory speculation, or deferred exception handling to create transient windows. In this work, we introduce a new transient execution primitive, called GadgetSpinner. We exploit the Loop Stream Detector (LSD) in Intel processors to perform out-of-loop-bounds execution and perform illegal operations. Our key observation is that the LSD holds on to an old copy of branch predictions from the first iteration of the loop and keeps using this copy until a branch misprediction occurs, i.e., advances beyond the loop bound. We exploit the delay between the speculative iteration of the loop and when the branch misprediction is resolved. In this paper, we analyze the transient execution of the LSD and perform end-to-end attacks to (1) perform illegal reads from protected memory regions, (2) bypass Intel SGX and extract the weights of a trained CNN model in DNNL library, (3) break Kernel ASLR (KASLR), and finally (4) perform cross-core/cross-process attacks. We also show that many defenses for prior transient execution attacks, like secure Branch Prediction Unit (BPU) designs, fail to protect against GadgetSpinner.

Modern superscalar processors execute instructions out-of-order, but commit them in program order to provide precise exception handling and safe instruction retirement. However, in-order instruction commit is highly conservative and holds on to critical resources far longer than necessary, severely limiting the reach of general-purpose processors, ultimately reducing performance. Solutions that allow for efficient, early reclamation of these critical resources could seize the opportunity to improve performance. One such solution is out-of-order commit, which has traditionally been challenging due to inefficient, complex hardware used to guarantee safe instruction retirement and provide precise exception handling. In this work, we present NOREBA, a processor for Non-speculative Out-of-order REtirement via Branch Reconvergence Analysis. In NOREBA, we enable non-speculative out-of-order commit and resource reclamation in a light-weight manner, improving performance and efficiency. We accomplish this through a combination of (1) automatic compiler annotation of true branch dependencies, and (2) an efficient re-design of the reorder buffer from traditional processors. By exploiting compiler branch dependency information, this system achieves 95% of the performance of aggressive, speculative solutions, without any additional speculation, and while maintaining energy efficiency.
